QBit 3 VET

Slim.Smart.Strong

CHISON QBit 3 Vet, a slim console color Doppler system, offers ideal veterinary patient care with its easy mobility, smart features, and outstanding performance. Its streamlined workflow enhances clinical confidence and speeds up diagnostic decisions for a wide range of animal care needs.

Specifications

15" LED Monitor (-90°-90°rotatable)
Built-in battery (optional ), excellent for VET condition
Full screen display mode
Triplex mode for easy diagnose
Compact design
Covering all examination needs in your diagnose
Advanced technologies: Q-Beam, Q-flow

Application

Features

SonoPW

The PW sample gate can be set up to 4.
Synchronous display of image and calculation results.
Clinical applications: mainly used for measuring bloodflow velocity before and after arterial stenosis in animalsand for assessing the degree of embolism.

TDI-SonoPW

Myocardial movements were evaluated simultaneously.
Up to 4 sample gates.
Provides more diagnostic information.
Offers a more effective diagnostic basis.
Clinical applications: Observing the different movementspeeds of the heart can determine whether there arelocal lesions and can also evaluate early diastolic function.

Strain and Strain Rate

It is a tissue Doppler ultrasound technique used for evaluating myocardial function.
Ventricular diastolic function and wallmotion can be quantitatively evaluated.

Elastography

Utilizes the tissue's own pulsation to generatepressure and form an elastic image.
Equipped with quantitative methods (gray scaleto elastic area ratio, strain rate ratio).
Clinical application: Assessment of lesions insmall organs and superficial tissues, such asthe animal liver.
